Jaw Crushing Equipment Mining Machine
Introduction to Jaw Crusher
Jaw crushing equipment represents one of the most reliable and robust solutions for primary crushing in mining operations. First invented in 1858, jaw crusher have evolved significantly while maintaining their fundamental principle of using two vertical jaws to compress and crush materials.
At Liming Heavy Industry, we’ve refined this traditional technology with modern engineering innovations. Our jaw crushing mining machines utilize a deep crushing chamber and optimized nip angle to deliver superior throughput while maintaining energy efficiency. The periodic compression movement of the movable jaw against the fixed jaw effectively breaks down even the hardest ores and rocks with compressive strengths up to 300 MPa.
Robust Construction
Heavy-duty frame design with high-quality steel components ensures longevity in demanding applications.
Optimized Crushing Chamber
Deep symmetrical crushing chamber with large feed opening prevents bridging and enhances capacity.
Advanced Adjustment System
Dual-wedge discharge setting adjustment replaces traditional pad adjustment for easier operation.
Application Scope
Our jaw crushing equipment serves diverse industries and materials, demonstrating exceptional versatility across multiple sectors:
Industries Served
- Mining and metallurgy
- Quarrying and aggregate production
- Construction and building materials
- Concrete and cement production
- Industrial minerals processing
- Coal and energy production
Material Compatibility
Our jaw crushing mining machines effectively process various materials including granite, basalt, iron ore, copper ore, gold ore, limestone, quartz, diabase, iron ore, gold ore, copper ore, and other hard rocks with compressive strength up to 300MPa.
Capacity and Types
Liming Heavy Industry offers a comprehensive range of jaw crushing equipment with varying capacities to match different production requirements:
C6X Series Jaw Crusher
The C6X series represents our latest generation of jaw crushing equipment with remarkable technological innovations:
| Model | Feed Opening (mm) | Max Feed Size (mm) | Motor Power (kW) | Capacity (t/h) |
|---|---|---|---|---|
| C6X110 | 1100×850 | 720 | 160 | 150-500 |
| C6X125 | 1250×950 | 800 | 160 | 200-650 |
| C6X145 | 1450×1100 | 930 | 200 | 300-750 |
| C6X160 | 1600×1200 | 1000 | 250 | 400-900 |
| C6X200 | 2000×1500 | 1200 | 400 | 600-1500 |
PEW European Version Jaw Crusher
Our PEW series jaw crushing mining machines are particularly suitable for medium and fine crushing of materials with compressive strength not exceeding 280MPa:
| Model | Feed Opening (mm) | Max Feed Size (mm) | Motor Power (kW) | Capacity (t/h) |
|---|---|---|---|---|
| PEW860 | 860×1100 | 720 | 132-160 | 200-500 |
| PEW1100 | 1100×1200 | 930 | 185-200 | 300-650 |
Technology and Innovation
At Liming Heavy Industry, we continuously integrate cutting-edge technologies to enhance the performance and reliability of our jaw crushing equipment:
Structural Innovations
Our C6X series features a bolted frame structure without welding, which eliminates stress concentration issues common in traditional welded designs. This innovative approach enhances structural reliability while allowing easier replacement of damaged components.
Optimized Crushing Chamber
Through computer-aided analysis and finite element analysis technology, we’ve optimized the crushing chamber geometry and motion parameters of the movable jaw. This results in reasonable inertia moment and greater crushing stroke, delivering higher crushing efficiency at the same energy consumption level.
Premium Components
We use only high-quality materials for critical components including front/rear walls, side plates, jaw plates, bearing seats, movable jaw body, and main shaft. International brand bearings and couplings ensure reliable operation under heavy-load conditions.
Intelligent Adjustment System
The dual-wedge adjustment system replaces traditional pad adjustment methods, making discharge setting adjustments simpler and more precise. This innovation significantly reduces the time required for maintenance and adjustment operations.
Vibration Reduction Technology
Elastic limit blocks and rubber damping devices replace rigid foundation connections, effectively absorbing peak vibration loads and reducing mutual impact between the crusher and foundation.
Common Challenges and Solutions
Mining operations often face specific challenges that can impact productivity. Our jaw crushing equipment is designed to address these issues effectively:
Rapid Wear of Jaw Plates
Challenge: Traditional jaw crusher experience uneven wear on jaw plates, with the lower section near the discharge opening wearing faster.
Solution: Our jaw crushing mining machines feature reversible and symmetrical jaw plates made from high manganese steel. This design allows plates to be interchanged when worn, extending service life and reducing operating costs.
Frequent Blockages
Challenge: Material bridging and blockages in the crushing chamber cause unplanned downtime.
Solution: The deep, symmetrical “V” shaped crushing chamber in our jaw crushing equipment prevents bridging while the large feed opening accommodates larger feed materials without clogging.
High Energy Consumption
Challenge: Traditional jaw crusher consume excessive power, increasing operational costs.
Solution: Optimized crushing kinetics and precision-balanced flywheels in our jaw crushing mining machines reduce energy consumption by 15-30% compared to conventional models.
Complex Maintenance
Challenge: Many jaw crusher require extensive downtime for routine maintenance and adjustments.
Solution: Our innovative bolted frame design and easily accessible components simplify maintenance procedures. The centralized automatic lubrication system further reduces maintenance requirements.
Case Studies
The performance of our jaw crushing equipment is demonstrated in real-world applications across various industries:
Lead-Zinc Ore Processing Plant in Hunan
Location: Zhuzhou, Hunan Province
Equipment: PEW1100 European Version Jaw Crusher
Material Processed: Lead-zinc ore
Capacity: 8,000 tons per day
Results: The customer reported stable operation with no bridging issues, high throughput capacity, and excellent particle shape of the final product. The large feed size capability eliminated the need for primary crushing stage optimization.
Copper Ore Processing Line in Guangdong
Location: Jiangmen, Guangdong Province
Equipment: PEW860 European Version Jaw Crusher
Material Processed: Copper ore
Capacity: 5,000 tons per day
Results: The operation achieved higher than expected production capacity with low operating costs. The customer was so satisfied with the performance that they planned to purchase additional units to expand their production capacity.
Limestone Crushing and Grinding Plant in Shanxi
Location: Yangquan, Shanxi Province
Equipment: C6X Jaw Crusher
Material Processed: Limestone
Capacity: 1,200 tons per hour
Results: The integrated production line including C6X Jaw Crusher achieved continuous high-volume production with minimal downtime. The excellent reduction ratio allowed downstream equipment to operate at peak efficiency.
Why Choose Liming Heavy Industry
With decades of experience in manufacturing crushing equipment, Liming Heavy Industry stands out as the preferred partner for mining operations worldwide:
- Proven Expertise: With years of specialized experience in manufacturing jaw crushing equipment, we understand the unique demands of mining operations.
- Comprehensive Product Range: From our high-capacity C6X series to specialized PEW European version jaw crusher, we offer solutions for every application.
- Quality Assurance: Our manufacturing facilities span approximately 300,000 square meters with over 150 sets of various production and processing equipment.
- Global Support Network: With service points across 32 cities and countries, we provide prompt technical support, spare parts supply, and maintenance services.
- Innovation Focus: We dedicate significant resources to R&D, continuously improving our jaw crushing mining machines with the latest technological advancements.
- Customized Solutions: Our engineering team works closely with clients to develop customized configurations that match specific production requirements and material characteristics.
Conclusion
Liming Heavy Industry’s jaw crushing mining machines represent the pinnacle of crushing technology, combining reliability, efficiency, and innovation. Our C Series and JC Series jaw crushing equipment delivers superior performance across diverse applications.
With customizable solutions tailored to specific operational requirements, comprehensive aftermarket support, and continuous technological advancements, LHI stands as your trusted partner for all jaw crushing equipment needs.
